COSEC PATH DCFI, Finger and HiD iClass Card Based Compact Biometric Door Controller is a compact biometric door controller designed for modern organizations with fingerprint as its foremost credential. Supporting multiple credentials such as Fingerprint, Bluetooth® and RFID cards these controllers fulfill the time-attendance and access control needs of modern organizations. In particular, HID iClass cards are used for RFID authentication. Next, multiple connectivity options such as WiFi, Bluetooth®, PoE ensure flexibility in operations. The IP65 design delivers a consistent performance even in harsh weather conditions.
Finger and HiD iClass Card Based Compact Biometric Door Controller
COSEC PATH DCFI
- Multi-Credential Support – BLE, Fingerprint, and HiD iClass Card
- Massive Storage Capacity – 5,00,000 Event Logs, 50,000 Users
- Finger Template Storage:- 1:N Mode: 25,000,1:1 Mode: 1,00,000
- Multi-Connectivity Options – WiFi, Ethernet, Bluetooth®, RS-232, RS-485, Wiegand
- Compact Design with IP65 Rating
- Buzzer Alert with Tri-color Status LED
- Suitable for Access Control and Time-Attendance Applications
- Dimensions (mm): Width 50.5 x Height 160 x Depth 44
100 in stock
SPECIFICATIONS
SPECIFICATIONS
| Credential Support | BLE, Fingerprint and RFID Card |
| Template Per User | Up to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode) |
| Card Type | HID iCLASS, HID Prox (COSEC PATH DCFI) |
| Template Storage Capacity | SFM 6030: 25,000 (1:N) And 100,000 ( 1:1) |
| Cards Per User | Two |
| Events Buffer | 5,00,000 |
| Max. Users | 50,000 |
| RS-485 | Yes (115.2Kbps) |
| Battery Backup | No |
| Ethernet | Yes (10/100Mbps) |
| PoE | Yes (IEEE 802.3 af) |
| Exit Switch | Yes |
| Door Status Sense | Yes (2 State) |
| Door Lock Relay | Form C and SPDT Relay (Max 1A@30 VDC) |
| Door Lock Power | Internal 12V DC @ 0.5 Amp |
| Reader Interface types | RS-232 and Wiegand IN/OUT |
| Buzzer | Yes |
| LED | Single LED (TriColor ) |
| CPU | Cortex A8 800 MHz |
| Flash Memory | 512 MB |
| RAM Memory | 512 MB |
| Input Power | 12V DC @ 2A |
| Humidity | 5% to 95% RH Non – Condensing |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Tamper Detection | Yes |
| IP65 | Verified |
| Certification | CE and BIS |
| Dimension (mm) | 50.5X160X44 |
| Weight (kgs) | 0.27 |
| Wi-Fi | Yes (802.11 b/g/n) |
Application Diagram
DOWNLOADS
DOWNLOADS
Datasheet
|
