    EM Proximity Card Based Ultra Fast Door Controller
    Back to products
    Next product
    Face and MiFare Classic Card Based Smart Door Controller

    Face and EM Proximity Card Based Smart Door Controller

    COSEC ARGO FACEE

    • Multi-Credentials inclusive of Contactless Technology – Face, BLE, PIN, and EM Proximity Card
    • Multi-Connectivity Options – Wi-Fi, PoE, Ethernet, BLE, USB, 3G/4G/LTE
    • Massive Storage Capacity – 50,000 Users, 2,00,000 Face Templates
    • Deep Face Learning Algorithm with Adaptive Understanding
    • Weatherproof and Vandal Resistant
    • Suitable for Access Control and Time-Attendance Applications
    • Dimensions (mm): Width 74 x Height 186 x Depth 50

    100 in stock

    Contact Us
    Call Now Schedule Call Email
    ADD TO QUOTE
    This product is already in quote request list
    Browse the list
    Add to wishlist
    SKU: 3000001372 Categories: ACTA, Hardware
    Share
    • Description
    • SPECIFICATIONS
    • DOWNLOADS
    Description

    COSEC ARGO FACEE – Face and EM Proximity Card Based Smart Door Controller an instant Face-recognition Door Controller unifying aesthetics, hygiene standards, and technology. With the best of the technology inclusive of top-class processors, a deep learning algorithm, and two in-built cameras, it takes over the dual roles of an access device and a surveillance camera.
    A Tech marvel designed for elegant Performance, COSEC ARGO FACEE, with EM Proximity card support, brings in contactless authentication, high-speed Identification eliminating grouping, and accurate imaging even in low light conditions, to name a few benefits.

    SPECIFICATIONS

    SPECIFICATIONS

    CREDENTIAL
    Human Face Yes
    PIN Yes
    BLE – Mobile Yes
    CAPACITY
    User Profiles 50,000
    Face Templates 200,000
    Max. Templates Per User 30
    Event Logs 500,000
    FACE RECOGNITION
    Algorithm Deep Learning-based Face Recognition
    Fake Face Detection Yes
    Face Identification 1:200,000 in < 1 sec
    1:1 in < 0.5 sec
    Face Enrolment Enrolment Station
    Upload Images
    Recognition Distance 30cm – 120cm (0.3m – 1.2m)
    Recognition Height 140cm – 198cm (1.4m – 1.98m)
    GENERAL SPECIFICATIONS
    Dimensions (HxWxD) 186mm x 74 mm x 50mm
    (7.3” x 3” x 2 “)
    Weight 650gms (1.433 lbs)
    Display 3.5″ IPS LCD (Touch Screen)
    Display Resolution 480 x 320 Pixel
    Gorilla Glass Yes (Gorilla Glass 3)
    CPU Quad-Core ARM Cortex-A7 @ 1.5 GHz
    GPU Built-in 2 TOPS Neural Network Computing Performance
    RAM 2 GB DDR4
    Flash Memory 16 GB eMMC
    SD Card No
    Tamper Detection Yes
    Buzzer Yes
    IR LEDs Yes
    Ingress Protection IP65
    Vandal Proof IK06
    Certificate CE, FCC, BIS, UL, RoHS
    Operating Temperature 0°C to 50°C
    Storage Temperature -20°C to 60°C
    Humidity 5% to 95 % RH Non-Condensing
    CAMERA
    RGB Camera 2MP Surveillance Grade, IR Blocked
    Infrared Camera 2MP Surveillance Grade, IR Band Pass
    Camera Sensors SONY IMX 307, EXMOR Technology, STARVIS Series
    COMMUNICATION
    Ethernet Yes (10/100 Mbps – 1 port)
    PoE Yes (IEEE 802.3 af)
    WiFi Yes (802.11 b/g/n)
    3G/4G/LTE Yes (Additional USB Modem)
    BLE Yes (8m Range)
    USB Yes (USB 2.0)
    Micro USB-Type B
    INTERFACE
    Exit Switch Interface Yes
    External Reader Support Yes (MATRIX and 3rd Party)
    External Reader Interface

    • RS232
    • Wiegand
    • Power
    • 12VDC @ 0.5A

    LED and Buzzer Control
    Allowed – GREEN LED

    Wiegand Yes (Selectable IN/OUT)
    IN: 26 Bit format OUT:
    Configurable
    Door Lock Relay Yes (30VDC @ 2A, Dry Contacts NO/NC/COM)
    Door Lock Power Internal PoE Power: 12VDC @ 0.250 A
    Internal Adapter Power 12VDC @ 0.5 A
    External Power 12VDC @ 2A
    INSTALLATION
    Wall Mount Yes – Plastic Back Cover with Screws
    Flush Mount Yes – Metal Bracket with Screws
    Power Adapter 12VDC @ 2A (CE, FCC, UL, BIS)
    Card
    Proximity Cards EM Prox
    (Separate variant for each card type. HID PROX requires HID iCLASS type)
    Application Diagram
    DOWNLOADS

    DOWNLOADS

    Datasheet

    Brochure
