Matrix presents COSEC ARC DC200P – Next generation Two-way Door Controller. It is developed on the concept of ‘IP to door’. It proactively utilizes Wi-Fi or PoE+ infrastructure to interact with Door controllers on each door with minimum wiring requirements. This helps in improving solution reliability and at the same time, gives a drastic reduction in installation cost.
Also, With its SSL capabilities, COSEC ARC DC200P secures communication between the server and the door controller, helping organizations with simple access or critical security.
Two Door Access Controller
COSEC ARC DC200P
- Face, Finger, Card, PIN and BLE as Credential using External Readers
- Massive Storage Capacity – 50,000 Users, 5,00,000 Event Logs
- Multi Connectivity Options – Wi-Fi, Ethernet, BLE, USB, 3G/4G/LTE, RS-485
- Support Third Party Acces Control Readers over Wiegand Interface
- Available in Direct Door Mode and Panel Door Mode
- Provides Power to Readers and Lock over PoE/PoE+ interface
- Industry Standard Rail Mounting and Wall Mounting Options
- In-Built Status Alert with Tri-Color LED
- Suitable for Access Control and Time-Attendance Applications
- Dimensions (mm): Width 78 X Height 140 X Depth 25
100 in stock
Description
SPECIFICATIONS
SPECIFICATIONS
| GENERAL | |
|---|---|
| Maximum Readers | Up to 2 Readers (Wiegand and/or RS-485) |
| Maximum Doors | 2 |
| Maximum Users | 50,000 |
| COMMUNICATION | |
|---|---|
| Ethernet | Yes, 10/100 Mbps |
| RS-485 | Yes |
| SSL Enabled | Yes |
| Bluetooth | Yes (BLE-10m) |
| Wi-Fi | Yes |
| PoE+ | Yes, IEEE 802.3 af/at |
| OPERATION MODES | |
|---|---|
| Direct Door Mode | With COSEC CENTRA (with COSEC PANEL LITE V2 for Dual Door Mode) |
| Panel Door Mode | With COSEC PANEL |
| READERS | |
|---|---|
| Reader Power Output | Max. 12V DC @ 0.250A |
| Reader Types | 2 Reader Port for any Wiegand or Matrix Reader |
| Interface | RS-485 (For Matrix Reader Only) and Wiegand IN |
| IN/OUT PORTS | |
|---|---|
| Exit Switch Port | Yes |
| Door Status Sense | Programmable NO, NC |
| Door Lock Relay | Maximum 30 V DC @ 2A, Relay SPDT, Form C |
| Door Lock Power | 12V DC @ 0.5A |
| AUX-IN Port | Yes |
| AUX-Out Port | 30V DC @ 2A, Relay SPDT, Form C |
| AUDIO VISUAL | |
|---|---|
| LED | Yes (Tri Color) |
| ELECTRICAL | |
|---|---|
| Input Power | PoE+ (IEEE 802.3 af),12VDC @ 1.8A OR 12 VDC @ 2A Power Adaptor |
| CPU | ARM Processor, 800MHz |
| Memory | 256MB Flash, 256MB RAM |
| PHYSICAL | |
|---|---|
| Mounting | Wall Mount OR Din-Rail Mounting Options |
| Dimensions (W x H x D) (mm3) | 140mm(H) x 78mm(W) x 25mm(D) |
| Weight (kg) | 0.45 (0.99 lbs.) |
| ENVIRONMENTAL | |
|---|---|
| Humidity | 5% to 95% RH Non-Condensing |
| Operating Temperature | -10°C to + 50°C (32°F to 122°F) |
| System Integration | API for Software Integration |
| CERTIFICATIONS | |
|---|---|
| CE, FCC, RoHS and UL | |
Application Diagram
Deployment
Deployment
DOWNLOADS
DOWNLOADS
Datasheet
|
