Utilize Existing Telephony

  • GSM FXS Gateway Integrates with Existing PBX or VoIP Systems
  • Make Mobile Calls from Existing Telephone Instruments
  • Save on New Investments
  • Seamless Transition to GSM Connectivity

Easy Programming Interface

  • GSM FXS Gateway with Intuitive Web-based Configuration Interface
  • User-friendly GUI for Gateway Settings
  • Easy to Use and Faster Deployment
  • Easy Access to Advanced Configuration Options

Least Cost Routing

  • Eliminate the Cumbersome Manual Selection of Call Provider
  • Optimize Communication Feasibility with GSM FXS Gateway
  • Real-time Analysis of Call Rates and Routing Options
  • Efficient Utilization of GSM/4G Services to Minimize Expenses

Features

Up to 4 GSM-3G-4G SIM Support

4 GSM/3G SIM Support

GSM FXS Gateway seamlessly integrates with multiple SIM cards for flexible, reliable, and cost-effective voice and data communication

Up to 4 GSM-3G-4G SIM Support

Automatic Number Translation

Automatic Number Translation

Automatically converts dialed numbers to their corresponding destination numbers for seamless and accurate call handling

Automatic Number Translation

Call Detail Record

Call Detail Record

Comprehensive and detailed information about each call for monitoring, analysis, and billing purposes

Call Detail Record

Allowed and Denied List

Allowed and Denied List

Manage call permissions by specifying which numbers are permitted or blocked, ensuring effective call management and security

Allowed and Denied List

Hotline Extension Setting

Hotline Extension Setting

Designated extension to automatically establish a call without dialing, streamlining communication and improving responsiveness

Hotline Extension Setting

Emergency Number Dialing

Emergency Number Dialing

Direct and immediate access to emergency services for prompt assistance and peace of mind with GSM FXS Gateway

Emergency Number Dialing

Built-in Antenna Splitter

Built-in Antenna Splitter

Efficiently divides antenna signals to multiple devices for improved reception and reliable communication

Built-in Antenna Splitter

Quad Band Support

Quad Band Support

Seamless communication across multiple frequency bands for enhanced reach and connectivity

Quad Band Support

Emergency Dialing even Without SIM Card

Emergency Dialing even Without SIM Card

GSM FXS Gateway offers crucial lifeline during critical situations for swift communication and assistance

Emergency Dialing even Without SIM Card

Applications

Fixed Media Gateways

Fixed Media Gateways

Fixed Media Gateways

Architecture Diagram

SIMADO GFX44 gsm fxs Gateway Architecture Diagram

Technical Specifications

Models:

SIMADO GFX44

  • GSM to Analog Voice Gateway with Four GSM SIM and Four FXS Ports

SIMADO GFX44

  • 3G/4G to Analog Voice Gateway with Four 3G/4G SIM and Four FXS Ports
Mobile Port:

Frequency Bands

  • Quad-band GSM850, EGSM900, DCS1800, PCS1900
    Tri-band WCDMA 850/1900/2100 MHz or Tri-band
    WCDMA 900/1900/2100 MHz

Compliance

  • ETSI GSM Phase2/2+

SIM Interface

  • 1.8, 3V SIM Interface

Antenna

  • 1.8/2.5 *dBi, 50, SMA (Male) Connector,
    Fixed Omni Directional Swivel Antenna 1.8/3.0 *dBi, 50, SMA (Male) Connector,
    Omni Directional with a Cable Three Meters Long
FXS Port:

Physical Connector

  • RJ11

Dialling

  • DTMF and Pulse (10/20PPS)

CLI Presentation

  • DTMF, FSK ITU-T V.23 and FSK Bellcore 202A CLI

Call Maturity

  • Polarity Reversal
Power Supply:

Input

  • External Power Adaptor
    Input: 90 – 265VAC, 47 – 63Hz
    Output: 12VDC@2A

Power Consumption

  • 8W (Typical)
Mechanical:

Dimensions (WxHxD)

  • 23.1 X 5.5 X 16.2 cm (9.09”x2.16”x6.37”)

Unit Weight

  • 1.00 kg (2.21 lbs) Approx.

Shipping Weight

  • 1.83 kg (4.03 lbs) Approx.

Mounting Options

  • Wall Mount and Table Top
Environmental:

Operating Temperature

  • 0° C to +45° C (32° F to +113° F)

Storage Temperature

  • -20° C to +70° C (-4° F to +158° F)

Operating Humidity

  • 5 – 95% RH (Non-condensing)

Storage Humidity

  • 0 – 95% RH (Non-condensing) at 40° C

Certifications

CE
RoHS
FCC
